• Donaldson Lube Filter, Spin-On Full Flow Donaldson Blue - Donaldson DBL7483
1 1

Lube Filter, Spin-On Full Flow Donaldson Blue - Donaldson DBL7483

Lube Filter, Spin-On Full Flow Donaldson Blue - Donaldson DBL7483

£32.30
£32.30
Sale Sold out
Shipping calculated at checkout.
In the unlikely event of a delivery delay exceeding 10 working days, would you accept an alternative brand equivalent? (If no, we will contact you in the event of an unexpected delay)

Donaldson DBL7483

Lube Filter, Spin-On Full Flow Donaldson Blue
Outer Diameter 4.25 inch (108 mm)
Thread Size 1 1/8-16 UN
Length 10.31 inch (262 mm)
Gasket OD 3.90 inch (99 mm)
Gasket ID 3.54 inch (90 mm)
Efficiency 99% 15 micron
Efficiency Test Std ISO 4548-12
Media Type Synteq
Collapse Burst 149 psi (10.3 bar)
Type Full-Flow
Style Spin-On
Brand Donaldson BLUE®
View full details

Specifications

Attributes

  • Outer Diameter: 108 mm (4.25 inch)
  • Thread Size: 1 1/8-16 UN
  • Length: 262 mm (10.31 inch)
  • Gasket OD: 99 mm (3.90 inch)
  • Gasket ID: 90 mm (3.54 inch)
  • Efficiency 99%: 15 micron
  • Efficiency Test Std: ISO 4548-12
  • Media Type: Synteq
  • Collapse Burst: 10.3 bar (149 psi)
  • Type: Full-Flow
  • Style: Spin-On
  • Brand: Donaldson BLUE®

Packaged Dimensions

  • Packaged Length: 0.35 FT
  • Packaged Width: 0.35 FT
  • Packaged Height: 0.87 FT
  • Packaged Weight: 1.158 kg (2.55 lb)
  • Packaged Volume: 0.003 m3 (0.11 ft3)

Other Information

  • Country of Origin: United States
  • NMFC Code: 069100-05
  • HTS Code: 8421230090
  • UPC Code: 742330103951

Cross Reference

Manufacturer Name Manufacturer Part Number Notes
ARIEL A0661
ARIEL A661
GARDNER DENVER H27096
RENAULT VI 7421561278 High efficiency without Wrench Removal Tool
RENAULT VI 41035000133555
VMC LF7483
VOLVO 21707134
