• Donaldson Hydraulic Filter, Spin-On Duramax - Donaldson P164059
1 1

Hydraulic Filter, Spin-On Duramax - Donaldson P164059

Hydraulic Filter, Spin-On Duramax - Donaldson P164059

£83.87
£83.87
Sale Sold out
Shipping calculated at checkout.
In the unlikely event of a delivery delay exceeding 10 working days, would you accept an alternative brand equivalent? (If no, we will contact you in the event of an unexpected delay)

Donaldson P164059

Hydraulic Filter, Spin-On Duramax
View full details

Specifications

Attributes

  • Filter Note: Water Glycol Compatibility with Fluorocarbon Seals
  • Outer Diameter: 97 mm (3.82 inch)
  • Thread Size: 1 3/8-12 UN
  • Length: 239.78 mm (9.44 inch)
  • Gasket OD: 70 mm (2.76 inch)
  • Gasket ID: 63 mm (2.48 inch)
  • Efficiency Beta 1000: 22 micron
  • Efficiency Test Std: ISO 16889
  • Style: Spin-On
  • Series: HMK04/24
  • Brand: Duramax®
  • Media Type: Synthetic

Packaged Dimensions

  • Packaged Length: 0.105 m (4.20 inch)
  • Packaged Width: 0.103 m (4.10 inch)
  • Packaged Height: 0.253 m (10.10 inch)
  • Packaged Weight: 1.348 kg (2.97 lb)
  • Packaged Volume: 0.003 m3 (0.10 ft3)

Other Information

  • Country of Origin: United States
  • NMFC Code: 069100-10
  • HTS Code: 8421298090
  • UPC Code: 742330015803

Cross Reference

Manufacturer Name Manufacturer Part Number Notes
BIG A 92492
CATERPILLAR 3I0580
KRESS 205955
TAYLOR 1005003
WALGAHN-MOTORENTECHN 810957
