• Donaldson Hydraulic Filter, Spin-On - Donaldson P165243
1 1

Hydraulic Filter, Spin-On - Donaldson P165243

Hydraulic Filter, Spin-On - Donaldson P165243

£30.48
£30.48
Sale Sold out
Shipping calculated at checkout.
In the unlikely event of a delivery delay exceeding 10 working days, would you accept an alternative brand equivalent? (If no, we will contact you in the event of an unexpected delay)

Donaldson P165243

Hydraulic Filter, Spin-On
Outer Diameter 3.90 inch (99 mm)
Thread Size 1 5/16-12 UN
Length 5.75 inch (146.05 mm)
Gasket OD 3.50 inch (89 mm)
Gasket ID 3.23 inch (82 mm)
Efficiency Beta 2 7 micron
Style Spin-On
Media Type Cellulose
Primary Application CASE/CASE IH D59062
View full details

Specifications

Attributes

  • Outer Diameter: 99 mm (3.90 inch)
  • Thread Size: 1 5/16-12 UN
  • Length: 146.05 mm (5.75 inch)
  • Gasket OD: 89 mm (3.50 inch)
  • Gasket ID: 82 mm (3.23 inch)
  • Efficiency Beta 2: 7 micron
  • Style: Spin-On
  • Media Type: Cellulose
  • Primary Application: CASE/CASE IH D59062

Packaged Dimensions

  • Packaged Length: 0.100 m (4.00 inch)
  • Packaged Width: 0.100 m (4.00 inch)
  • Packaged Height: 0.153 m (6.10 inch)
  • Packaged Weight: 0.513 kg (1.13 lb)
  • Packaged Volume: 0.002 m3 (0.06 ft3)

Other Information

  • Country of Origin: United States
  • NMFC Code: 069100-04
  • HTS Code: 8421298090
  • UPC Code: 742330017098

Cross Reference

Manufacturer Name Manufacturer Part Number Notes
A P PARTS 2093
AC DELCO PF854
ALLIS-CHALMERS 2017858
ALLIS-CHALMERS 20177895
ALLIS-CHALMERS 2017789
ALLIS-CHALMERS 4905902
AMERICAN MOTORS CORPORATION SFO0282
AMERICAN PARTS 2023
AMERICAN PARTS 92422
BAKER 737AN1
BARBER-GREENE 10R59
BARBER-GREENE 4512175110
BARBER-GREENE 4512175140
BIG A 92422
BIG A 92650
CASE/CASE IH D59062
CATERPILLAR 3I0675
CHAMPION ROAD 10924
CHAMPION ROAD 11439
COOPERS HEM6070
DANA 621005
DANA 621000
DANA F501
DANA F50125
EATON 515303801
EXMAN SFO0282
FIAT 72017789
FIAT 72017858
FIAT 2017858
FORD 9576P165243
JACOBSEN 353937
KRALINATOR L146
LOESING 20170
LOESING 020170
MARVEL 4512175125
MARVEL 4512175110
MARVEL 4512171110
MARVEL 291000
MARVEL 272SERIES
MARVEL 272
MARVEL M32981110
MARVEL 4552177110
MARVEL 452177110
MARVEL M4123
MARVEL 4512177120
MARVEL 4512177110
MARVEL M37547120
MARVEL 4512175140
MARVEL M2425
P.B.R. BC109610
STEIGER 28007
TOTAL SOURCE AC4905902
TOWMOTOR 972415
VMC HF165243
WALGAHN-MOTORENTECHN 811010
WALGAHN-MOTORENTECHN 00811010
WHITE 207300253
WHITE 515303801
YALE 515303801
YALE 513303801

Equipment Compatibility

Equipment Year Equipment Type Equipment Options Engine Engine Option
ALLIS-CHALMERS 500 - FORKLIFT - - 500 -
ALLIS-CHALMERS 600 - FORKLIFT - - 600 -
ALLIS-CHALMERS 615 - BACKHOE LOADER - - 615 -
ALLIS-CHALMERS 615 - BACKHOE LOADER - - 615 -
ALLIS-CHALMERS I40 - TRACTOR - - I40 -
ALLIS-CHALMERS I400 - TRACTOR - - I400 -
ALLIS-CHALMERS I60 - TRACTOR - - I60 -
ALLIS-CHALMERS I600 - TRACTOR - - I600 -
ALLIS-CHALMERS I600D - TRACTOR - - I600D -
ALLIS-CHALMERS I60D - TRACTOR - - I60D -
BARBER-GREENE SA41 - ROAD EQUIPMENT - INTERNATIONAL UB264 -
BARBER-GREENE SA41 - ROAD EQUIPMENT - INTERNATIONAL UC263 -
BARBER-GREENE SB41 - ROAD EQUIPMENT - INTERNATIONAL UB264 -
CASE/CASE IH 1816 - SKID STEER LOADER - - 1816 -
CASE/CASE IH 1816B - SKID STEER LOADER - - 1816B -
CASE/CASE IH 1816C - SKID STEER LOADER - - 1816C -
CASE/CASE IH 850D - TRACTOR TRACKED - CASE/CASE IH A336BD -
GROVE RT48 - CRANE MOBILE - FORD 6 CYL -
GROVE RT49 - CRANE MOBILE - FORD 6 CYL -
JOHN DEERE 52 - COMBINE - - 52 -
