• Donaldson Hydraulic Filter, Cartridge - Donaldson P171568
1 1

Hydraulic Filter, Cartridge - Donaldson P171568

Hydraulic Filter, Cartridge - Donaldson P171568

£45.95
£45.95
Sale Sold out
Shipping calculated at checkout.
In the unlikely event of a delivery delay exceeding 10 working days, would you accept an alternative brand equivalent? (If no, we will contact you in the event of an unexpected delay)

Donaldson P171568

Hydraulic Filter, Cartridge
View full details

Specifications

Attributes

  • Outer Diameter: 140 mm (5.51 inch)
  • Inner Diameter: 65.5 mm (2.58 inch)
  • Length: 203 mm (7.99 inch)
  • Efficiency Beta 1000: 23 micron
  • Bypass Valve: Yes
  • Bypass Valve Setting LR: 1.5 bar (22 psi)
  • Collapse Burst: 10 bar (145 psi)
  • Style: Cartridge
  • Media Type: Synthetic

Packaged Dimensions

  • Packaged Length: 0.150 m (6.00 inch)
  • Packaged Width: 0.148 m (5.90 inch)
  • Packaged Height: 0.275 m (11.00 inch)
  • Packaged Weight: 1.315 kg (2.90 lb)
  • Packaged Volume: 0.006 m3 (0.23 ft3)

Other Information

  • Country of Origin: Italy
  • NMFC Code: 069100-08
  • HTS Code: 8421298090
  • UPC Code: 742330022115

Cross Reference

Manufacturer Name Manufacturer Part Number Notes
F.B.O. CR50003
LHA TIE2425A2
LOESING 140092
