• Donaldson Hydraulic Filter, Cartridge - Donaldson P170098
1 1

Hydraulic Filter, Cartridge - Donaldson P170098

Hydraulic Filter, Cartridge - Donaldson P170098

£59.05
£59.05
Sale Sold out
Shipping calculated at checkout.
In the unlikely event of a delivery delay exceeding 10 working days, would you accept an alternative brand equivalent? (If no, we will contact you in the event of an unexpected delay)

Donaldson P170098

Hydraulic Filter, Cartridge
Outer Diameter 3.60 inch (91.5 mm)
Inner Diameter 1.91 inch (48.6 mm)
Length 7.41 inch (188.1 mm)
Outlet Diameter 2.48 inch (63 mm)
Efficiency Beta 1000 9 micron
Collapse Burst 149 psi (10.3 bar)
Style Cartridge
Media Type Synthetic
View full details

Specifications

Attributes

  • Outer Diameter: 91.5 mm (3.60 inch)
  • Inner Diameter: 48.6 mm (1.91 inch)
  • Length: 188.1 mm (7.41 inch)
  • Outlet Diameter: 63 mm (2.48 inch)
  • Efficiency Beta 1000: 9 micron
  • Collapse Burst: 10.3 bar (149 psi)
  • Style: Cartridge
  • Media Type: Synthetic

Packaged Dimensions

  • Packaged Length: 0.100 m (4.00 inch)
  • Packaged Width: 0.103 m (4.10 inch)
  • Packaged Height: 0.213 m (8.50 inch)
  • Packaged Weight: 0.440 kg (0.97 lb)
  • Packaged Volume: 0.002 m3 (0.08 ft3)

Other Information

  • Country of Origin: United States
  • NMFC Code: 133320
  • HTS Code: 8421298090
  • UPC Code: 742330019948

Cross Reference

Manufacturer Name Manufacturer Part Number Notes
BEHRINGER BE310812AV
BEHRINGER BE983061
BEHRINGER BE932636Q
BEHRINGER BEGO1068
CATERPILLAR 3I1729
LOESING 140179
MP FILTRI MP4051
VMC HF170098
