Breather, Hydraulic Spin-On - Donaldson P564425
Breather, Hydraulic Spin-On - Donaldson P564425
Regular price
£19.80
Regular price
Sale price
£19.80
Unit price
/
per
Shipping calculated at checkout.
Couldn't load pickup availability
Donaldson P564425
Breather, Hydraulic Spin-On| Outer Diameter | 3.66 inch (93 mm) |
| Thread Size | 3/4 NPT |
| Length | 3.66 inch (93 mm) |
| Efficiency 98% | 3 micron |
| Media Type | Cellulose |
| Style | Spin-On |
Share
Collapsible content
Specifications
Attributes
- Outer Diameter: 93 mm (3.66 inch)
- Thread Size: 3/4 NPT
- Length: 93 mm (3.66 inch)
- Efficiency Beta 2: 3 micron
- Media Type: Cellulose
- Style: Spin-On
Packaged Dimensions
- Packaged Length: 0.110 m (4.40 inch)
- Packaged Width: 0.110 m (4.40 inch)
- Packaged Height: 0.178 m (7.10 inch)
- Packaged Weight: 0.640 kg (1.41 lb)
- Packaged Volume: 0.002 m3 (0.08 ft3)
Other Information
- Country of Origin: Mexico
- NMFC Code: 069100-05
- HTS Code: 8421392590
- UPC Code: 742330161401
Cross Reference
| Manufacturer Name | Manufacturer Part Number | Notes |
|---|---|---|
| AMERICAN PARTS | 93469 | |
| ARROW SPECIALTY | 47203811 | |
| ATLAS COPCO | 50903236 | |
| ATLAS COPCO | 2650903236 | |
| BIG A | 93469 | |
| CATERPILLAR | 4354789 | |
| CATERPILLAR | 0775232 | |
| CATERPILLAR | 6G0078 | |
| CATERPILLAR | 775232 | |
| ELGIN | 6203819 | |
| GEHL | 137798 | |
| GRAINGER | 2NUD8 | |
| GROVE | 7437000159 | |
| GROVE | 9258100007 | |
| INGERSOLL RAND | 50903236 | |
| INGERSOLL RAND | 51612364 | |
| INGERSOLL RAND | 57023582 | |
| INTRUPA | 83367 | |
| INTRUPA | 83367Q | |
| INTRUPA | IF4027 | |
| JLG | 1340021 | |
| JOHN DEERE | F309181 | |
| LHA | GBS1003N12 | |
| MCNEILUS | 1106849 | |
| MCNEILUS | 40261 | |
| MCNEILUS | 1300005 | |
| MCNEILUS | 1072562 | |
| NEW WAY | M725 | |
| NEW WAY | 106138 | |
| PETTIBONE | PR120177 | |
| SNORKEL | GN60559 | |
| STEIGER | 181633 | |
| TENNANT | 53430 | |
| VMC | AF564425 | |
| VOLVO | 16020704 | |
| WASTEBUILT | G1A4969 | |
| WASTEBUILT | 84005500 | |
| WASTEBUILT | ABF310 |
Equipment Compatibility
| Equipment | Year | Equipment Type | Equipment Options | Engine | Engine Option |
|---|---|---|---|---|---|
| CATERPILLAR 621E | - | SCRAPER | 600 SERIES | CATERPILLAR 3406 | - |
| CATERPILLAR 621E | - | SCRAPER | - | CATERPILLAR 3306 | - |
| CATERPILLAR 621F | - | TRACTOR | - | CATERPILLAR 3406 | - |
| CATERPILLAR 621F | - | TRACTOR | - | CATERPILLAR 3406C | - |
| CATERPILLAR 627E | - | SCRAPER | - | CATERPILLAR 3406 | - |
| CATERPILLAR 657E | - | SCRAPER | 600 SERIES | CATERPILLAR 3412C, 3412E | - |
| CATERPILLAR PM565 | - | PLANER | - | CATERPILLAR 3408 | - |
| CATERPILLAR PM565B | - | PLANER | - | CATERPILLAR 3408C | - |
| GEHL 7800 | - | SKID STEER LOADER | - | YANMAR 4TNE106 | - |
| LIEBHERR MULTI-HANDLER | - | LOADER | - | - MULTI-HANDLER | - |
| LIEBHERR MULTI-HANDLER 4500 | - | LOADER | - | - MULTI-HANDLER 4500 | - |
