• Donaldson Air Filter, Primary Duralite - Donaldson B105006
1 1

Air Filter, Primary Duralite - Donaldson B105006

Air Filter, Primary Duralite - Donaldson B105006

£56.18
£56.18
Sale Sold out
Shipping calculated at checkout.
In the unlikely event of a delivery delay exceeding 10 working days, would you accept an alternative brand equivalent? (If no, we will contact you in the event of an unexpected delay)

Donaldson B105006

Air Filter, Primary Duralite
Outlet Diameter 4.02 inch (102 mm)
Body Diameter Maximum 10.50 inch (266.7 mm)
Body Length 10.50 inch (266.7 mm)
Efficiency 99.9
Efficiency Test Std ISO 5011
Rated Flow LR 448 cfm (12.7 m³/min)
Rated Flow MR 590 cfm (16.7 m³/min)
Rated Flow HR 678 cfm (19.2 m³/min)
Restriction LR 4.02 inch H2O (102 mm H2O)
Restriction MR 5.98 inch H2O (152 mm H2O)
Restriction HR 7.99 inch H2O (203 mm H2O)
Family ECB
Type Primary
Style Round
Brand DuraLite™
Media Type Cellulose
View full details

Specifications

Attributes

  • Outlet Diameter: 102 mm (4.02 inch)
  • Body Diameter Maximum: 266.7 mm (10.50 inch)
  • Body Length: 266.7 mm (10.50 inch)
  • Efficiency: 99.9
  • Efficiency Test Std: ISO 5011
  • Rated Flow LR: 12.7 m³/min (448 cfm)
  • Rated Flow MR: 16.7 m³/min (590 cfm)
  • Rated Flow HR: 19.2 m³/min (678 cfm)
  • Restriction LR: 102 mm H2O (4.02 inch H2O)
  • Restriction MR: 152 mm H2O (5.98 inch H2O)
  • Restriction HR: 203 mm H2O (7.99 inch H2O)
  • Family: ECB
  • Type: Primary
  • Style: Round
  • Brand: DuraLite™
  • Media Type: Cellulose

Packaged Dimensions

  • Packaged Length: 0.270 m (10.80 inch)
  • Packaged Width: 0.273 m (10.90 inch)
  • Packaged Height: 0.320 m (12.80 inch)
  • Packaged Weight: 2.136 kg (4.71 lb)
  • Packaged Volume: 0.024 m3 (0.87 ft3)

Other Information

  • Country of Origin: United States
  • NMFC Code: 069100-06
  • HTS Code: 8421310090
  • UPC Code: 742330000649

Cross Reference

Manufacturer Name Manufacturer Part Number Notes
BIG A 93790
CATERPILLAR 3I0005
CUMMINS 3912986
CUMMINS 1403597
FORD 9576B105006
FREIGHTLINER DNB105006
HAVAM HD1925
JOHN DEERE RE47573
KIRLOSKAR 6H112801000
SCANIA 1394527
SDMO 330560556
VMC AH105006
